Corsa Velocity Short Stack Air Filter Kit For
Weber 34 DCOE to 50 DCOE Side Draft & UP Draft Carburetors

This is a Brand New Product Developed By CORSA VELOCITA LLC.  specially Designed and Dynode for Weber side Draft Carburetors For Maximum air flow and venture speed.
These Air Filter's  short stack design of only 3"inches makes it very applicable to use in tight engine bays with clearance issues for side draft carburetors.
The filter Housing and the Mounting Flange are made of Die-Cast Aluminum Alloy that is polished for a eye catching luster, the air filter element is nested in a Nylon Housing for ease of replacing and cleaning by un-screwing the filter housing.
One Of The Best Features Of This short Velocity Stacks are large intake diameter of 3" and actual filters that will save your engine from out side air dirt and rocks.
All Parts are made in USA.
 unquestionable quality with all spare part availability for future replacements.
Applications:
Weber Side Draft 40 DCOE / 42 DCOE / 44 DCOE / 46 DCOE / 48 DCOE and 50 DCOE
This Kit Can Be Fitted To Other Brands Of Side Draft Carburetors As well , Such As SOLEX," SK " and " DELORTO "
Ordering :
Please Specify Type and Carburetor Size ( BORE )
Mounting Flange Bolt Pattern is 2 X 65mm ( 2.56in. )
Each Kit Comes complete with Two  Velocity Stacks and Two Filters Pre Assembled and Stainless Steel SHCS.
Installation:
No Alteration or Modification Needed.
This Kit comes complete and Pre Assembled with Four Stainless 6mm. SHCS.
You May Remove the Existing Weber 6mm. studs to use the Provided SHCS ( if your carburetor have the studs ) .
The filter housing is a billet machined round threaded cap and simply unscrew the top and the filter element is within your reach to clean and replace.
Filters are dry type no oil is needed.

Please Contact us if you have any questions.
